Tabletop Touchscreen Monitors for Construction
From preconstruction planning to final walkthroughs, Volanti’s 55", 43", and 32" tabletop touchscreens bring clarity and precision to blueprint reviews and construction workflows.
One Display for Every Stage of Construction
The Volanti Tabletop adapts to the way construction teams work. Whether you’re mapping out preconstruction schedules, making markups during active builds, or managing punch lists in the field, this portable large-format display gives you the clarity and flexibility to work smarter at every phase.
Durability Meets Practical Design
The Tabletop combines strength and adaptability with a powder-coated aluminum enclosure, a solid stainless steel stand that adjusts manually for comfort on any surface, and a design that stays quiet and reliable in offices or trailers without internal fans.
Compatible With the Tools You Already Use
Volanti Tabletop displays connect easily to Windows 10 and 11 devices, giving your team the flexibility to work directly in Bluebeam, Revit, Procore, and other construction software without extra hardware or adapters. They’re also optimized for Volanti Plan Viewer and Kanban Board for teams already moving toward digital workflows.
Features & Specs
| Specification | 32" | 43" | 55" |
| Display Type | 32" TFT, LED Backlit | 43" TFT, LED Backlit | 55" TFT, LED Backlit |
| Display Resolution | 3840 x 2160 (4k, Ultra-HD) | 3840 x 2160 (4k, Ultra-HD) | 3840 x 2160 (4k, Ultra-HD) |
| Aspect Ratio | 16:9 | 16:9 | 16:9 |
| Brightness | 350 nit (cd/m²) | 500 nit (cd/m²) | 700 nit (cd/m²) |
| Contrast | 1100:1 | 1100:1 | 4000:1 |
| Colors | 1.06 Billion | 1.06 Billion | 1.06 Billion |
| Viewing Angle | 178 degrees Horizontal and Vertical | 178 degrees Horizontal and Vertical | 178 degrees Horizontal and Vertical |
| Frame Rate | 60Hz | 60Hz | 60Hz |
| Video Inputs/Outputs | HDMI x2: 3840 x 2160 @60Hz DVI: 3840 x 2160 @30Hz | HDMI x2: 3840 x 2160 @60Hz DVI: 3840 x 2160 @30Hz | HDMI x2: 3840 x 2160 @60Hz DVI: 3840 x 2160 @30Hz |
| Touch Connection | USB-C, HDMI and USB-B | USB-C, HDMI and USB-B | USB-C, HDMI and USB-B |
| Remote Commands | Connect via Ethernet | Connect via Ethernet | Connect via Ethernet |
| Touch Screen | PCAP, Finger & Stylus, palm rejection | PCAP, Finger & Stylus | PCAP, Palm Rejection, Finger & Stylus |
| Mounting | Stand: Tabletop manual tilt stand, approx 30 to 70 adjustment in 10 increments plus flat VESA 300 x 300mm / 200 x 200mm | Stand: Tabletop manual tilt stand, approx 30 to 70 adjustment in 10 increments plus flat VESA 400 x 400mm | Stand: Tabletop manual tilt stand, approx 30 to 70 adjustment in 10 increments plus flat VESA 400 x 400mm |
| Glass, Surface Treatment | 3 mm Toughened, anti-glare | 3 mm Toughened, anti-glare | 3 mm Toughened, anti-glare |
| Warranty | 2 Years | 2 Years | 2 Years |
| Audio | Stereo Speakers | Stereo Speakers | Stereo Speakers |
| User Controls | OSD Buttons | OSD Buttons | OSD Buttons |
| Power Consumption | 100 - 240VAC 50/60Hz / 125 Watts | 100 - 240VAC 50/60Hz / 125 Watts | 100 - 240VAC 50/60Hz / 125 Watts |
| Dimensions | 29"W x 17"H x 3"D | 40"W x 23.8"H x 1.9"D | 50"W x 26"H x 22.6" |
| Weight | 25 lbs | 35 lbs | 45 lbs |
| Shipping Dimensions | 46"W x 10"H x 23"D | 57"W x 36"H x 10"D | 57"W x 36"H x 10"D |
